Slotted Hole Perforated Metal Sheet

Slotted Hole Perforated Metal Sheet can be offered with requested material,including stainless steel,aluminum sheet,carbon steel,galvanized steel and copper,etc.Both hole size and sheet size can make to order.

Product parameters

Slotted Hole Perforated Metal Sheet also called oblong hole perforated metal,vertical line of hole is paralell,but other two sides of hole is arc shape,so it looks a little different with rectangle shape because of the arc ends.The sheet size for slotted hole perforated metal sheet usually 4ftx8ft.We can produce perforated sheets with slotted holes for every need in Stainless Steel, Mild Steel, Galvanized, Aluminium, Copper, Brass, in standard sizes, at measure, perforated in zones and as drawing, in small and mid quantities.

Slotted Hole Perforated Metal Sheet

Perforated Metal MeshPerforated Metal Mesh

Perforated Metal Mesh

Specifications for perforated metal mesh:

Material

Low carbon steel ,Stainless steel sheet, Galvanized steel ,Aluminum metal

Thickness

0.2mm--20mm


Aperture

0.5--200mm

Size

1200*2400mm   1220*2440mm Or cut to size

Hole shape

Rectangular,   square, Diamond , round,Triangular,Louver, irregular hole

Hole arrangement

90°staggered,45°staggered,   60°staggered , 90°straight

Surface treatment

Galvanized   ,Powder coating, Anodized, Fluorocarbon coating

Advantages

Light   weight,durable application,good sound absorption,various hole design

Application

Machinery,filtration,enclosure,   equipment,handicrafts production


Product Features

Slotted Hole Perforated Metal Sheet Features:

  • light weight & low cost,

  • large ventilation,

  • translucent,

  • sound-absorbing,

  • high toughness

  • easy to install


Welcome to email us your enquiry on perforated metal, referring to below detail specifications:

MaterialAlum sheet, alum ally sheet, carbon steel,galvanized steel, stainless steel,
Thickness0.1mm-10mm
Hole size x pitchCustomized as request
Sheet sizeMax width 1800mm, Max length 4000mm

Scope of application

We carry Slotted Hole Perforated Metal Sheet in a wide array of hole shapes, sizes, gauges, and material types. This makes perforated metal ideal for many applications ranging from metal screens to metal signage. The most common applications for perforated metal include:

  • Preforated Fencing

  • Perforated Railings

  • Perforated Screens

  • Perforated Grilles

  • Perforated Cladding and sunshade.

  • Wall & ceiling panels.

  • Act as sieves for grain & seeds cleaning and drying machine.

  • Mill of flour and rice.
