Copper Expanded Metal

Copper expanded metal is a lightning protection method that can not only act as a receiver to receive lightning, but also act as a down conductor to conduct lightning well.

Product parameters

Micro Expanded Copper Mesh Foil for lightning strike protection

AISN Code

AISNCU-66

AISNCU-107

AISNCU-141

AISNCU-195

Weight(g/sqm)

73

107

141

195

Metal thickness

0.051mm

0.051mm

0.076mm

0.076mm

LWD

2.54mm

2.54mm

3.175mm

2.54mm

Overall thickness

0.102mm

0.127mm

0.127mm

0.127mm

Open area

84%

76%

79%

70%


Annealed

Annealed

Annealed

Annealed


Flattened Micro Expanded Copper Mesh Foil for lightning strike protection

AISN Code

AISNCU-66F

AISNCU-107F

AISNCU-141F

AISNCU-195F

AISNCU-175F

Weight(g/sqm)

73

107

141

195

175

Metal thickness

0.051mm

0.051mm

0.076mm

0.076mm

0.041mm

LWD

2.54mm

2.54mm

3.175mm

2.54mm

2.54mm

Overall thickness

0.051mm

0.051mm

0.076mm

0.076mm

0.045mm

Open area

84%

76%

79%

70%

52%


Flattened

Annealed

Flattened

Annealed

Flattened

Annealed

Flattened

Annealed

Flattened

Annealed


Product Features

As an important lightning protection method, lightning protection metal mesh has achieved very important applications in aircraft. The common metal mesh for lighting protection includes woven mesh, copper expanded metal foil and perforated sheet. The disadvantage of the woven mesh is that the surface of the composite curvature is difficult to cover, which affects the aerodynamic performance, and the lap resistance between the metal wires of the woven mesh is relatively large, and the lightning protection effect is far less than that of the copper expanded metal. The woven wire mesh is also prone to breakage and disintegration due to the strong electromagnetic force generated by the lightning current.

Scope of application

Important application of copper expanded metal:

Aerospace

Wind Energy

Battery mesh

Electrolyzer

Filtration

EMI shielding

Automotive

flue gas denitrification
